ขั้วต่อสายไฟ 3 ช่อง รุ่น PCT223 SUMO
WIRE CONNECTOR 3 PIN MOD.PCT223 SUMO






ขั้วต่อสายไฟ
ขั้วต่อสายไฟ สำหรับเสียบสายไฟ 3 ด้าน รุ่น PCT223 SUMO
WIRE CONNECTOR 3 PIN MOD.PCT223 SUMO
คุณสมบัติ (Feature)
- ขั้วต่อสายไฟ สำหรับต่อสายไฟ
- ใช้ได้กับสายไฟทั้งชนิดแข็งและอ่อน
- สามารถถอดเปลี่ยนสายไฟได้ตามต้องการ
- ขั้วต่อสายไฟ ทนความร้อน ไม่ลามไฟ
- ติดตั้งง่ายและรวดเร็ว
- wire connectors for connecting wires.
- Compatible with solid wire and fine wire.
- Easy-to-use.
- High temperature resistance.
- Quick and easy to install.
ข้อมูลทางเทคนิค (Specification)
- ขนาดสายไฟ (Applicable wires)
- สายไฟแข็ง (Solid wire) : 0.5-4 mm²
- สายไฟอ่อน (Fine wire) : 0.5-2.5 mm²
- แรงดันไฟฟ้า (Voltage rating) : 400V
- กระแสไฟ (Current rating) : 32A
- ความต้านทานคอนแทค (Contact resistance) : ≤0.015Ω
- ความต้านทานฉนวน (Insulation resistance) : ≥1000MΩ
- อุณหภูมิ (Temperature range) : -40°C ถึง 105°C℃
- ตัวนำไฟฟ้า (Conductor) : Copper
- พลาสติก (Plastic parts) : PC UL94V 2 (0)
- คลิปล็อค (Cliplock) : Stainless steel 301
วิธีใช้งาน ขั้วต่อสายไฟ 3 ช่อง (How to use)
- ปอกสายไฟให้ยาวประมาณ 10-15 มม.
- งัดกิ๊บล็อคขึ้น
- เสียบสายไฟเข้าไปให้สุดแล้วกดกิ๊บล็อคลง
- Use a wire stripper to remove about 10-15 mm of this insulation from wire ends.
- Pull up the clip lock.
- Insert wire into the hole and push down the clip lock.
คำแนะนำ (Suggestion)
- ควรติดตั้งและเดินสายไฟโดยช่างไฟฟ้า
- ตรวจสอบให้แน่ชัดว่าสายไฟต่อเข้ากับขั้วต่อสายไฟแน่นสมบูรณ์
- Should install the cable and connector by electrical technician.
- Check the cable and connector to ensure they are connected tightly.
คำเตือน (Warning)
- ห้ามใช้กับขนาดสายไฟ และกระแสไฟเกินกว่าที่กำหนด
- ห้ามใช้งานขั้วต่อสายไฟที่ชำรุดเสียหาย
- ต้องตัดระบบไฟฟ้าก่อนการติดตั้งหรือซ่อมบำรุงทุกครั้ง
- ห้ามเก็บไว้ในที่เปียกชื้น
- ห้ามดัดแปลงหรือใช้งานผิดประเภท
- Do not use with the bigger wire and over current on the specification.
- Do not use the damaged connector.
- Cut off the electrical system before installing or repair the connector.
- Do not keep in wet or moisture condition area.
- Do not modify or misuse.
ขั้วต่อสายไฟ
ขั้วต่อสายไฟ 3 ช่อง รุ่น PCT223 SUMO
WIRE CONNECTOR 3P MOD.PCT223 SUMO
คุณสมบัติ (Feature)
- ขั้วต่อสายไฟ สำหรับต่อสายไฟ
- ใช้ได้กับสายไฟทั้งชนิดแข็งและอ่อน
- สามารถถอดเปลี่ยนสายไฟได้ตามต้องการ
- ขั้วต่อสายไฟ ทนความร้อน ไม่ลามไฟ
- ติดตั้งง่ายและรวดเร็ว
- wire connectors for connecting wires.
- Compatible with solid wire and fine wire.
- Easy-to-use.
- High temperature resistance.
- Quick and easy to install.
ข้อมูลทางเทคนิค (Specification)
- ขนาดสายไฟ (Applicable wires)
- สายไฟแข็ง (Solid wire) : 0.5-4 mm²
- สายไฟอ่อน (Fine wire) : 0.5-2.5 mm²
- แรงดันไฟฟ้า (Voltage rating) : 400V
- กระแสไฟ (Current rating) : 32A
- ความต้านทานคอนแทค (Contact resistance) : ≤0.015Ω
- ความต้านทานฉนวน (Insulation resistance) : ≥1000MΩ
- อุณหภูมิ (Temperature range) : -40°C ถึง 105°C℃
- ตัวนำไฟฟ้า (Conductor) : Copper
- พลาสติก (Plastic parts) : PC UL94V 2 (0)
- คลิบล็อค (Cliplock) : Stainless steel 301
วิธีใช้งาน ขั้วต่อสายไฟ 3 ช่อง (How to use)
- ปอกสายไฟให้ยาวประมาณ 10-15 มม.
- งัดกิ๊บล็อคขึ้น
- เสียบสายไฟเข้าไปให้สุดแล้วกดกิ๊บล็อคลง
- Use a wire stripper to remove about 10-15 mm of this insulation from wire ends.
- Pull up the clip lock.
- Insert wire into the hole and push down the clip lock.
คำแนะนำ (Suggestion)
- ควรติดตั้งและเดินสายไฟโดยช่างไฟฟ้า
- ตรวจสอบให้แน่ชัดว่าสายไฟต่อเข้ากับขั้วต่อสายไฟแน่นสมบูรณ์
- Should install the cable and connector by electrical technician.
- Check the cable and connector to ensure it is connected tightly.
คำเตือน (Warning)
- ห้ามใช้กับขนาดสายไฟและกระแสไฟเกินกว่าที่กำหนด
- ห้ามใช้งานขั้วต่อสายไฟที่ชำรุดเสียหาย
- ต้องตัดระบบไฟฟ้าก่อนการติดตั้งหรือซ่อมบำรุงทุกครั้ง
- ห้ามเก็บไว้ในที่เปียกชื้น
- ห้ามดัดแปลงหรือใช้งานผิดประเภท
- Don't use with the bigger wire and over current on the specification.
- Don't use the damaged connector.
- Cut off the electrical system before install or fix the connector.
- Don't store it in the wet or moisture condition
- Don't modify
